Natural White Plastic pe1000 Plate with 42mm Thickness UHMWPE sheet

42mm Thickness Natural White Plastic pe1000 Plate/UHMWPE sheet

1)UHMWPE plastic sheet Specifications:

1. Thickness: 2- 300mm.
2. Width: 1000mm,1200,1300mm,1500mm,2000mm

3. Length: no limit
4. Surface: Smooth, Sand or corrugation.

5. Heating size change rate under 80°C: 52%  (standard ≤60% ).
6. Tensile Strength in lengthways: 8.08 Mpa (Standard ≥7.0Mpa).

7. Tensile Strength in transverse: 7.71 Mpa (Standard ≥7.0Mpa).

8. Any color, machining with drawing available.

2,Ultrahigh-molecular-weight polyethylene (UHMWPE) is defined by ASTM as “polyethylene with molecular weight over three million (weight average). Our UHMWPE products have molecular weight range from 1 ~ 9 million. Being chemically similar to HDPE, UHMWPE shows the typical polyethylene characteristics of chemical inertness, lubricity, and electrical resistance, while its very long substantially linear chains provide greater impact strength, abrasion resistance, toughness, and freedom from stress cracking.However, this very high molecular weight also makes it difficult to process the polymer by standard moulding techniques. Compression molding of sheets and ram extrusion of profiles are the normal manufacturing techniques.

3)Application of UHMWPE boron sheet

1. MINING INDUSTRY

REASONS:Good Impact Strength, High Wear Resistance and Low Friction Properties.
APPLICATIONS: Linings for Bunkers, Chutes and Railway Wagons, Conveyor Rollers, Scraper Blades, Impact Bars.

2. CHEMICAL INDUSTRY
REASONS: Excellent Chemical Resistance and Toughness, Easily Machined.
APPLICATIONS: Pump Housings, Seals, Gaskets, Stopcocks, Valves, Electroplating Barrels, Filter Press Plates.

3. FILTRATION INDUSTRY
REASONS: Excellent Chemical Resistance, Low Friction, High Wear
Resistance.
APPLICATIONS: Filter Plates, Vacuum Seal Strips, Support Rollers, Belt Slide Plates, Cloth
Guides, Belt Guide Rollers, Belt and Cloth Tensioners.

4. PAPER INDUSTRY
REASONS: Low Coefficient of Friction, High Wear Resistance.
APPLICATIONS: Suction Box Covers and Bars, Foils, Guide Blades, Slide Deckles, Rollers.

5. PORT, DOCK INSTALLATIONS, SHIPBUILDING
REASONS:Good Impact Strengths, Low Friction, UV. Resistance.
APPLICATIONS:Dock Fenders, Buffer Strips, Cable Guides, Weir Plates, Lock Gates.

6. BREWERY, BOTTLING AND CANNING
REASONS: High Wear Resistance, Low Friction, Good Impact Strengths, Food Approved.
APPLICATIONS: Wear Strips, Chain Guides, Starwheels, Can Guides, Chain Tensioners, Dead Plates, Feed worms, Bearings, Rollers.

7. FOOD AND PREPARATION
REASONS:F.D.A. Approval, Non - Stick, Good Impact Strengths.
APPLICATIONS: Food Preparation Tables, Cutting Boards, Stirring Paddles, Mincer
Rammers, Rolling Pins, Knife Holders, Butchers Blocks.
