Popular size:2440(L)*1220(W)*12.7(T)mm (4'x8'x1-1/2")
Thickness: 12.7mm, 15mm, 18mm, 20mm etc
- Cleat height: 5mm
- Color: Black/Dark Green (other colors available)
Pattern both sides OR smooth on one side.
Various sizes and thickness can be offered to suit your need. (12.7mm, 15mm, 18mm, 20mm)
PRODUCTS DESCRIPTION
Ground protection mat is designed to preserve soft and sensitive ground conditions for machinery and vehicles, which are reusable for many times and 100% recyclable after use. It is an ideal alternative of the highly expensive aluminum protection systems or the "rot and replace" culture of timber for ground protection.
1) Extrude ground mat size available:
Series No. | Size (mm) | Thickness with texture (mm) | Unit weight (kg) | Effective Surface Area (sqm) | Load Capacity (tons) |
01 | 2000*1000*10 | 20 | 22.6 | 2.00 | 30 |
02 | 2440*1220*12.7 | 22.7 | 42 | 2.98 | 40 |
03 | 5900*2000*28 | 36 | 346 | 11.8 | 120 |
04 | 2900*1100*12.7 | 22.7 | 45 | 3.20 | 50 |
05 | 3000*1500*15 | 25 | 74 | 4.50 | 80 |
06 | 3000*2000*20 | 28 | 128 | 6.00 | 100 |
07 | 2400*1200*12.7 | 22.7 | 40.5 | 2.88 | 40 |
Pattern both sides OR smooth on one side
We can adjust the size of ground mat according to your demand.
For the surface can be right side with type A, surface and back side with type B surface, Also both size with same surface is ok.
2). Advantage of HDPE ground protection mat:
Highest abrasion resistance of any polymer, 6 times more wear resistant than steel
Anti-Weather & Anti-Aging
Self-lubricating, Very low coefficient of friction
Excellent chemical & corrosion resistant
superior impact resistant, Noise- absorption, Vibration-absorption
Temperature range: -2600C ~ +800C; Very high resistance to cold,doesn't become fragile even under -1800
High tensile Strength
Non-Toxic and smell
UV resistance
Flame Retardant; Relatively low in water absorption
Excellent electrical properties
Good performance in resisting environment stress crack, 200 times of ordinary PE
No adhesion
Light weight and easier to handle and fix
Cost efficient; Resulting in low energy consumption
Does not rot, split or crack; 100% recyclable
Great liner material for industrial material handling applications
Easy Reprocessed
Ground protection mat Applications
The HDPE Ground mat is effective ground protection system.
▶ Protect your turf and provide access and traction over mud, sand, snow and other difficult surfaces.
▶ Create temporary roadways for all types of vehicles and equipment or large work pads for drilling,
▶ Administrative compounds, bone yards, temporary flooring, and other industrial application.
▶ Such as construction sites, golf courses, utilities, landscaping, tree care, cemeteries, drilling etc.
▶ And they are great to save heavy vehicles from getting trucked in mud.
FAQ
Q: Are you producer or trader?
A: We are producer.
Q: What are Abosn mat made from?
A: Most of our mats are made from Virgin High-Density Polyethylene (HDPE) which is extremely strong and lightweight. For black, we use some recycled HDPE.
Q: Are plastic mats prone to cracking or bending?
A: All plastic mats will flex to follow ground contours. However due to the exceptionally high grade of HDPE used in our premium mats, they are guaranteed against cracking or breaking.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-30 days if the goods are not in stock, it is according to quantity.
Q: What is the expected lifespan of your mats?
A: Our mats are designed for longevity with a typical lifespan of up to 10 years or more, depending on frequency and type of use.
Q: What is your terms of payment?
A: 50% pay in advance and balance upon the B/L.
